Winter is well and truly here, with temperatures dropping and snow flurries sweeping across the UK. Whilst visiting farms, the most common topic of conversation is the proposed budget. At Scot Agri, we understand the pressures the agricultural sector faces and are here to support you in any way we can—whether it’s through service, sales, advice, or simply offering a friendly face for a chat and a coffee. Don’t hesitate to give us a call!

On a positive note, Scot Agri has some exciting news this month: JCB has launched the much-anticipated new centre pivot telehandler – the JCB TM280 and TM280S. This compact agricultural telescopic wheel loader is perfect for those who need the power and comfort of the TM320S but in a smaller, more manoeuvrable chassis that fits into tighter spaces like low sheds.

The JCB TM280 and TM280S fit neatly between the TM180 and TM320, offering a balance of size and performance that’s ideal for a variety of agricultural tasks. Let's break down the key features that make these machines stand out.

Key Specifications

Dimensions

The TM280 and TM280S dimensions:

  • Height: 2,900mm
  • Width: 2,100mm

Lift Performance

Both machines have impressive lift performance:

  • Max lift: 2,750kg to a height of 4.8m
  • Max forward reach: 1,400kg

Powerful and Efficient Engines

Both the TM280 and TM280S are powered by the JCB DieselMax 4.8 litre, 4-cyclinder, Stage V engine. The engine has been cleverly lowered into the chassis, allowing the bonnet to be lowered as well, improving rear visibility for the operator.

TM280 Engine

  • Power: 109hp
  • Torque: 516Nm

TM280S Engine

  • Power: 130hp
  • Torque: 550Nm

Transmission Technology

The TM280 features a conventional hydrostatic transmission, while the TM280S is equipped with JCB’s advanced DualTech transmission. This unique blend of hydrostatic and mechanical drive delivers superior performance, especially when compared to traditional hydrostatic systems. The TM280S offers better road efficiency and finer control for tough jobs.

TM280 Transmission

  • Conventional Hydrostatic
  • Top Speed: 30kph

TM280S Transmission

  • JCB DualTech Transmission
  • Top Speed: 40kph

Hydraulics & Attachments

Both models are fitted with the 140 ltr/min piston pump hydraulic circuit, delivering 90 ltr/min of oil flow to auxiliary services. This is ideal for powering attachments like straw bedders, feed buckets, or bucket brushes.

One of the standout features on both models is the flow control dial located on the side console. This dial allows operators to easily adjust the flow rate and even switch the flow direction – making attachment use more intuitive and efficient.

Quick Hitch & Tyre Options

The TM280 and TM280S come with three quick hitch options:

  • Q-Fit
  • Pin and Cone
  • Euro Headstock

There are also two tyre sizes available straight from the factory:

  • Alliance 500/600 R22.5
  • Alliance 600/50 R22.5

Other sizes and brands may be available upon request!

Towing Capabilities

For those who require frequent towing, the TM280 and TM280S has multiple rear hydraulic hitch options:

  • 31mm Tow Hitch
  • 38mm Tow Hitch
  • Hydraulic Holdaway Tow Hitch

All hitches come standard with a single-line hydraulic brake system, with an option for a twin-line hydraulic brake system for added towing performance. If a hydraulic pickup hitch is selected, the machine also comes with a hitch camera for increased visibility.

JCB TM280 vs JCB TM280S

For customers looking for the perfect balance of productivity and performance, the TM280S is the model to choose, thanks to its DualTech Transmission and enhanced towing capabilities. The TM280, on the other hand, offers a more traditional hydrostatic option, perfect for those who don’t need the added speed or towing features but still require power and versatility.

To find out more about the JCB TM280 & TM280S, contact your local Scot Agri depot!
